Retrofit Screw-in base.
IQTraffiContro.com Professional LED Traffic Lights Manufacturer Exporter

Full Ball: More and more municipalities around the world are waving goodbye to incandescent traffic signals in favor of LED signals that deliver up to 90 percent greater energy efficiency and profound savings on maintenance costs. Rugged Illumination LED solutions like the new “Incandescent Look” give traffic management professionals a wide choice of robust, quality signal designs that can meet current ITE, Caltrans or EN 12368 standards. Illumination LED signals are designed and rigorously tested to handle conditions such as sun phantom, light uniformity and color washout, which incandescent signals struggle to perform against. Traffic signals LED signals that deliver up to 90 percent greater energy efficiency and profound savings on maintenance costs. Rugged LED solutions . LED signals are designed and rigorously tested to handle conditions such as sun phantom, light uniformity and color washout, which incandescent signals struggle to perform against.

Features and Specs

Up to 90% energy efficiency over incandescent
Long life of 50,000 hours plus
12-inch (300mm) & 8-inch (200mm) modules
OEM or retrofit installation
Quality/reliability
Colors
Red, Yellow & Green

Applications
Replaces incandescent lamps in full ball traffic signal applications
Arrow: IQ Pointing in the Right Direction. Traffic management professionals around the world are leaving maintenance intensive and energy hungry incandescent lamps by the curb and heading for the robust, high-reliability advantages that IQLED illumination LED arrow signals offer. With up to 90 percent energy savings and a long-rated life.

LED arrow signals outshine incandescent signals and offer significant advantages in dealing with sun phantom, light uniformity and color washout issues. Designed for direct retrofit or OEM applications LED arrow signals offer. With up to 90 percent energy savings and a long-rated life

Pedestrian Control: Walk Don't Walk this way. There’s no room for error when managing pedestrian traffic or synchronizing the movement of people and automobiles. LED Pedestrian Control Signals provide proven reliability and well-established LED-versus-incandescent advantages: up to 90% energy savings, longer life, fewer maintenance hassles and lower maintenance costs. Whether your needs require a standard LED outline, new “Incandescent Look”  or a more advanced unit with a digital countdown display, a vast collection of weatherproof LED pedestrian control signals that meet a variety of geographic and governmental specifications.

LED Pedestrian Control Signals provide proven reliability and well-established LED-versus-incandescent advantages: up to 90% energy savings, longer life, fewer maintenance hassles and lower maintenance costs

weatherproof LED pedestrian control signals.

IQ Traffic Control needs around the world can be as diverse as the geography. That’s why we developed the LED signal module for Europe and South America. Designed to operate in 230V applications, this “incandescent look” signal comes standard in 200 mm and 300 mm sizes to deliver up to 90% greater energy efficiency and lower maintenance costs.




Technical Specs

Application:
Enhancing all types of roadway signs (stop, yield, wildlife, dangerous corners, etc.)
Marking temporary and permanent road barricade marking
Flashing flagger
Enhancing safety at construction and detour zones
Indicating bridge and tunnel entrances
Marking hazards and infrastructure at industrial sites

BENEFITS

-Quick installation - no external wiring, cable trenching.
-Flexible design enables any configuration of bi-directional or dual flasher solution.
-Pays for itself within the first year of operation in the form of reduced installation, maintenance and servicing costs
-Self-powering capability means it can be installed anywhere
-Reliable operation 365 days per year at nearly any location on earth
-IQ Engineered for up to five (+) years of maintenance-free operation

Programmable Signals, LED Programmable Signals
LED Arrow Lenses
COUNTDOWN PEDESTRIAN SIGNAL
Available voltages 12VDC, 120VAC, 230VAC

12" RED LED BALL FLANGE MOUNT
8" RED LED BALL FLANGE MOUNT

12" RED LED BALL SCREWBASE
8" RED LED BALL SCREWBASE

12" AMBER LED BALL SCREWBASE
8" AMBER LED BALL SCREWBASE
12" AMBER LED BALL FLANGE MOUNT
8" AMBER LED BALL FLANGE MOUNT

12" Blue-green LED BALL SCREWBASE
8" Blue-green LED BALL SCREWBASE
12" Blue-green LED BALL FLANGE MOUNT
8" Blue-green LED BALL FLANGE MOUNT

12" RED LED ARROW SCREWBASE
12" RED LED ARROW FLANGE MOUNT

12" YELLOW LED ARROW SCREWBASE
12" YELLOW LED ARROW FLANGE MOUNT
12" Blue-green LED ARROW SCREWBASE
12" Blue-green LED ARROW FLANGE MOUNT

Traffic Plastic Cone, Height 18 Inches, Base 11 x 11 Inches, Stencil Plain, Color Red/Orange, Easy Stacking, Polyvinyl Chloride

Traffic Plastic Cone, Height 28 Inches, Base 14.5 x 14.5 Inches, Stencil Plain, Color Red/Orange, Easy Stacking, PVC

Traffic Reflective Cone, Height 28 Inches, Base 14.5 x 14.5 Inches, Stencil Two 6 and 4 Inches Reflective Collars, Color Red/Orange, PVC











Strictly technical information meant to be used by/for engineers and technicians. Please call us  with any inquiries regarding our capabilities. If we don't have it, we can make it. We recommend using your browsers search feature for this page.


The Type 1 LED signal unit shall replace the reflector, socket, gasket, and lens assembly of an incandescent signal section and shall fit the sections of an incandescent signal face as specified in Section 86-4.01, "Vehicle Signal Faces," of the Standard Specifications or may mount in the medium base lamp socket just as an incandescent bulb mounts. Traffic products are available in Type 1 or Type 2 configurations.

Type 1 LED signal module are designed to be installed in the door frame of a standard traffic signal housing. The lamp socket, reflector, reflector holder and lens used with an incandescent lamp shall not be used in a signal section in which a Type 1 LED signal module is installed.

Type 2 LED signal modules shall be designed to mount in the standard lamp socket normally used with an incandescent lamp. When a Type 2 LED signal module is used, a standard traffic signal lens in the door frame shall be used, at the option of the Contractor, the standard lens may be replaced with a translucent red lens to seal the signal section from weather. The installation of a Type 2 LED signal module shall not require any modification to the standard lamp socket or reflector.

Each Type 1 LED signal unit shall consist of a convex lens made of red ultraviolet stabilized hard-coated plastic or glass, LED circuit board with electronic switching module, and two conductors as specified in Section 86-4.01 C, "Electrical Components," of the Standard Specifications. The chromaticity of the red lens color shall match the chromaticity of the LEDs. Electrical connection can be accomplished by each conductor with spade tongue connector at the end, of sufficient length to reach a terminal strip mounted in the blue-green signal section housing with the red section door open. The unit shall be sealed with a one-piece neoprene EPDM (Ethylene, Propylene, Diene Monomers) gasket, shall be watertight, and shall be designed to be mounted to the door of the signal section housing using the same mounting method as the signal lens.

Electrical circuits shall be designed to limit the current flowing through each LED to 20 milliamps (ma) maximum at 120 volts AC (VAC). The failure of any LED shall only result in the loss of not more than 2 percent of the total LEDs in the signal unit.

Red LEDs shall be the ultra bright type and shall be rated for 100,000 hours of continuous operation at nominal current and at 25°C. The operating temperature range shall be from -30° C to 85° C. The LED emission spectrum shall meet the present ITE chromaticity diagram according to the 1931 CIE standard. The viewing angle shall be not less than 30°. Only Red and Yellow LEDs manufactured with Indium technology will be used. Blue-green LEDs will utilize Nitrite technology.

PEEK Wavelength: Red 630nm
PEEK Wavelength: Yellow 588nm
PEEK Wavelength: Blue-Green 505-510nm

Flange mount units consist of an LED array, electronics, rear housing and lens. Electrical connection can be accomplished by each conductor with spade tongue connector at the end, of sufficient length to reach a terminal strip mounted in the blue-green signal section housing with the red section door open. A black, polycarbonate rear housing, that has a water impermeable air vent installed, deters heat build-up in unit.

Screwbase units will consist of an LED array, electronics, rear housing and clear dust cover. An Edison medium screwbase adapter installs directly into lamp socket base and requires no modification to the signal housing. Indexed LEDs utilize, existing glass lens double convex design characteristics, for enhanced light throughput. A black, polycarbonate rear housing, that has a water impermeable air vent installed, deters heat build-up in unit.

MODEL 1932 12" RED LED BALL FLANGE MOUNT

Each LED utilized in a 12-inch circular red indication shall be rated at 2Ø 1/2 30º to be 1900 millicandelas (mcd) typical at 20 ma. The number of LEDs shall be sufficient to meet the light output specifications as outlined in Vehicle Traffic Control Signal Heads: a standard of the ITE. The LEDs shall be wired in a minimum of 65 parallel strings. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 12 inch red circular indication shall be 20 watts +/- .5 watts at 120 VAC. Model 1932 has 650 LEDs, and a red translucent hard-coated lens.

Also available in a screwbase version. MODEL 1932SB

MODEL RD12SB - 12" RED LED BALL SCREWBASE

Each LED utilized in a 12-inch circular red indication shall be rated at 2Ø 1/2 30º to be 1900 millicandelas (mcd) typical at 20 ma. The LEDs shall be wired in a minimum of 42 parallel strings. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 12 inch red circular indication shall be < 17 watts +/- .5 watts at 120 VAC. The RD12SB has 420 LEDS.

MODEL RD12FM - 12" RED LED BALL FLANGE MOUNT

Each LED utilized in a 12-inch circular red indication shall be rated at 2Ø 1/2 30º to be 1900 millicandelas (mcd) typical at 20 ma. The LEDs shall be wired in a minimum of 42 parallel strings. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 12 inch red circular indication shall be < 17 watts +/- .5 watts at 120 VAC. The RD12FM has 420 LEDS. Prismatic lens.

MODEL RD1210FM - 12" RED LED BALL FLANGE MOUNT

Each LED utilized in a 12-inch circular red indication shall be rated at 2Ø 1/2 30º to be 3800 millicandelas (mcd) typical at 20 ma. The LEDs shall be wired in a minimum of 16 parallel strings. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 12 inch red circular indication shall be < 11 watts +/- .5 watts at 120 VAC. The RD1210FM has 160 LEDS and a red tint lens.

This unit is on the CALTRANS pre-qualified list.

MODEL YL12SB - 12" AMBER LED BALL SCREWBASE

Each LED utilized in a 12-inch circular amber indication shall be rated at 2Ø 1/2 30º to be 2500 millicandelas (mcd) typical at 20 ma. The LEDs shall be wired in a minimum of 42 parallel strings. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 12 inch amber circular indication shall be < 17 watts +/- .5 watts at 120 VAC. The YL12SB has 420 LEDS.

MODEL YL12FM - 12" AMBER LED BALL FLANGE MOUNT

Each LED utilized in a 12-inch circular amber indication shall be rated at 2Ø 1/2 30º to be 2500 millicandelas (mcd) typical at 20 ma. The LEDs shall be wired in a minimum of 42 parallel strings. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 12 inch amber circular indication shall be < 17 watts +/- .5 watts at 120 VAC. The YL12FM has 420 LEDS. Prismatic lens.

MODEL YL1210FM - 12" AMBER LED BALL FLANGE MOUNT

Each LED utilized in a 12-inch circular amber indication shall be rated at 2Ø 1/2 30º to be 2500 millicandelas (mcd) typical at 20 ma. The LEDs shall be wired in a minimum of 19 parallel strings. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 12 inch amber circular indication shall be < 20 watts +/- .5 watts at 120 VAC. The YL1210FM has 190 LEDS and a yellow tint lens.

MODEL BG12SB - 12" Blue-green LED BALL SCREWBASE

Each LED utilized in a 12-inch circular blue-green indication shall be rated at 2Ø 1/2 30º to be 3800 millicandelas (mcd) typical at 20 ma. The LEDs shall be wired in a minimum of 6 parallel strings. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 12 inch blue-green circular indication shall be 15 watts +/- .5 watts at 120 VAC. The BG12SB has 258 LEDS.

MODEL BG12FM - 12" Blue-green LED BALL FLANGE MOUNT

Each LED utilized in a 12-inch circular blue-green indication shall be rated at 2Ø 1/2 30º to be 3800 millicandelas (mcd) typical at 20 ma. The LEDs shall be wired in a minimum of 6 parallel strings. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 12 inch blue-green circular indication shall be 15 watts +/- .5 watts at 120 VAC. The BG12FM has 258 LEDS. Prismatic lens.

MODEL BG1210FM - 12" Blue-green LED BALL FLANGE MOUNT

Each LED utilized in a 12-inch circular blue-green indication shall be rated at 2Ø 1/2 30º to be 3800 millicandelas (mcd) typical at 20 ma. The LEDs shall be wired in a minimum of 6 parallel strings. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 12 inch blue-green circular indication shall be 12 watts +/- .5 watts at 120 VAC. The BG1210FM has 190 LEDS. Prismatic lens.

This unit is on the CALTRANS pre-qualified list.

MODEL SWARROW

Each LED utilized in a 12 inch red arrow indication shall be rated at 2Ø 1/2 30º to be 1900 mcd, typical at 20 ma. The LEDs shall be arranged in lines and shall be wired in a minimum of 25 parallel strings. The power consumption of the 12 inch arrow indication shall be 7.5 watts +/- .5 watt. Model SWARROW has 240 LEDs and a red translucent lens.

MODEL SWARROW-SB 12" RED LED ARROW SCREWBASE

The specifications are the same as the Model Swarrow with the exception of the following. The unit will consist of an LED array, electronics, and an Edison medium screwbase adapter and will require no modification to the signal housing.

MODEL AR12SB - 12" RED LED ARROW SCREWBASE

Each LED utilized in a 12 inch red arrow indication shall be rated at 2Ø 1/2 30º to be 1900 mcd, typical at 20 ma. The LEDs shall be arranged in lines and shall be wired in a minimum of 12 parallel strings. The power consumption of the 12 inch arrow indication shall be 6 watts +/- .3 watt. Model AR12SB has 120 LEDs.

MODEL AR12FM - 12" RED LED ARROW FLANGE MOUNT

Each LED utilized in a 12 inch red arrow indication shall be rated at 2Ø 1/2 30º to be 1900 mcd, typical at 20 ma. The LEDs shall be arranged in lines and shall be wired in a minimum of 12 parallel strings. The power consumption of the 12 inch arrow indication shall be 9 watts +/- .3 watt. Model AR12FM has 120 LEDs and a red tint or masked lens available.

This unit is on the CALTRANS pre-qualified list.

MODEL AY12SB - 12" YELLOW LED ARROW SCREWBASE

Each LED utilized in a 12 inch red arrow indication shall be rated at 2Ø 1/2 30º to be 1900 mcd, typical at 20 ma. The LEDs shall be arranged in lines and shall be wired in a minimum of 12 parallel strings. The power consumption of the 12-inch arrow indication shall be 10 watts +/- .3 watt. Model AY12SB has 120 LEDs.

MODEL AY12FM - 12" YELLOW LED ARROW FLANGE MOUNT

Each LED utilized in a 12 inch red arrow indication shall be rated at 2Ø 1/2 30º to be 1900 mcd, typical at 20 ma. The LEDs shall be arranged in lines and shall be wired in a minimum of 12 parallel strings. The power consumption of the 12-inch arrow indication shall be 9 watts +/- .3 watt. Model AY12FM has 120 LEDs, and a yellow tint or masked lens available.

This unit is on the CALTRANS pre-qualified list.

MODEL AG12SB - 12" Blue-green LED ARROW SCREWBASE

Each LED utilized in a 12 inch blue-green arrow indication shall be rated at 2Ø 1/2 30º to be 3800 mcd, typical at 20 ma. The LEDs shall be arranged in lines and shall be wired in a minimum of 4 parallel strings. The power consumption of the 12 inch arrow indication shall be 10 watts +/- .3 watt. Model AG12SB has 120 LEDs.

MODEL AG12FM - 12" Blue-green LED ARROW FLANGE MOUNT

Each LED utilized in a 12 inch blue-green arrow indication shall be rated at 2Ø 1/2 30º to be 3800 mcd, typical at 20 ma. The LEDs shall be arranged in lines and shall be wired in a minimum of 4 parallel strings. The power consumption of the 12 inch arrow indication shall be 9 watts +/- .3 watt. Model AG12FM has 120 LEDs. A blue-green tint or masked lens is available.

This unit is on the CALTRANS pre-qualified list.

MODEL RDODOT08

Each LED utilized in an 8 inch circular red indication shall be rated at 2Ø 1/2 30º to be 1900 mcd typical at 20 ma. The number of LEDs shall be sufficient to meet the ITE specifications as outlined in Vehicle Traffic Control Signal Heads: a standard of the ITE. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 8 inch red circular indication shall be 10 watts +/- .5 watts at 120 VAC. Model RDODOT08 has 330 LEDs, and a red translucent hard-coated lens.

MODEL RD08SB - 8" RED LED BALL SCREWBASE

Each LED utilized in an 8 inch circular red indication shall be rated at 2Ø 1/2 30º to be 1900 mcd typical at 20 ma. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 8 inch red circular indication shall be 7 watts +/- .3 watts at 120 VAC. Model RD08SB has 180 LEDs.

MODEL RD08FM - 8" RED LED BALL FLANGE MOUNT

Each LED utilized in an 8 inch circular red indication shall be rated at 2Ø 1/2 30º to be 1900 mcd typical at 20 ma. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 8 inch red circular indication shall be 7 watts +/- .3 watts at 120 VAC. Model RD08FM has 180 LEDs. Prismatic lens.

MODEL RD0806FM - 8" RED LED BALL FLANGE MOUNT

Each LED utilized in an 8 inch circular red indication shall be rated at 2Ø 1/2 30º to be 3800 mcd typical at 20 ma. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 8 inch red circular indication shall be 8 watts +/- .3 watts at 120 VAC. Model RD0806FM has 86 LEDs. Prismatic lens.

This unit is on the CALTRANS pre-qualified list.

MODEL YL08SB - 8" Amber LED BALL SCREWBASE

Each LED utilized in an 8 inch circular amber indication shall be rated at 2Ø 1/2 30º to be 2500 mcd typical at 20 ma. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 8 inch amber circular indication shall be 7 watts +/- .3 watts at 120 VAC. Model YL08SB has 180 LEDs.

MODEL YL08FM - 8" Amber LED BALL FLANGE MOUNT

Each LED utilized in an 8 inch circular amber indication shall be rated at 2Ø 1/2 30º to be 2500 mcd typical at 20 ma. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 8 inch amber circular indication shall be 7 watts +/- .3 watts at 120 VAC. Model YL08FM has 180 LEDs. Prismatic lens.

MODEL YL0806FM - 8" Amber LED BALL FLANGE MOUNT

Each LED utilized in an 8 inch circular amber indication shall be rated at 2Ø 1/2 30º to be 2500 mcd typical at 20 ma. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 8 inch amber circular indication shall be 12 watts +/- .3 watts at 120 VAC. Model YL08O6FM has 86 LEDs. Yellow Tint lens.

This unit is on the CALTRANS pre-qualified list.

MODEL BG08SB - 8" Blue-green LED BALL SCREWBASE

Each LED utilized in an 8 inch circular Blue-green indication shall be rated at 2Ø 1/2 30º to be 3800 mcd typical at 20 ma. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 8 inch blue-green indication shall be 8 watts +/- .3 watts at 120 VAC. Model BG08SB has 180 LEDs.

MODEL BG08FM - 8" Blue-green LED BALL FLANGE MOUNT

Each LED utilized in an 8 inch circular blue-green indication shall be rated at 2Ø 1/2 30º to be 3800 mcd typical at 20 ma. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 8 inch blue-green indication shall be 8 watts +/- .3 watts at 120 VAC. Model BG08FM has 180 LEDs. Prismatic lens.

MODEL BG0806FM - 8" Blue-green LED BALL FLANGE MOUNT

Each LED utilized in an 8 inch circular blue-green indication shall be rated at 2Ø 1/2 30º to be 3800 mcd typical at 20 ma. The LEDs shall be arranged uniformly throughout the circle. The power consumption of the 8 inch blue-green indication shall be 10 watts +/- .3 watts at 120 VAC. Model BG08FM has 86 LEDs, and water clear lens.

PV18X10RD - PV - Red retrofit, 11 watts. This unit is on the CALTRANS pre-qualified list.

PV18X10YL - PV -Yellow retrofit, 15 watts. This unit is on the CALTRANS pre-qualified list.

PV30X6BG - PV -Blue-green retrofit, 15 watts. This unit is on the CALTRANS pre-qualified list.


Light Emitting Diode Pedestrian International symbol don't walk "HAND" Signal Indication. -- All pedestrian symbols don't walk "HAND" signal indications shall be provided with a light emitting diode (LED) signal unit. The LED signal unit shall replace the incandescent bulb of a Type A signal unit as specified in section 86-4.03, "Pedestrian Signal Faces," of the Standard Specifications, while requiring no further modification of the pedestrian signal head.

Each LED pedestrian signal shall consist of a LED matrix circuit board with electronic switching module, and a black polycarbonate rear housing, that has a water impermeable air vent installed, deters heat build-up in unit.

Electrical circuits shall be designed to limit the current flowing through each LED to 20 milliamps (ma) maximum at 120 Volts AC (VAC). The failure of any LED in a string shall only result in the loss of 2% or less of the total LEDs in the LED pedestrian signal unit.

MODEL HODOTPOR

Each LED utilized in a pedestrian signal "HAND" indication shall be rated at 2Ø 1/2 30º to be 1400 mcd typical at 20 ma. The LEDs shall be arranged to uniformly illuminate the raised hand symbol of the Type A pedestrian signal message plate. The LEDs shall be wired in a minimum of 3 parallel strings. The power consumption of the LED pedestrian signal unit shall be 8 watts +/- 1 watt at 120 VAC.

Model HODOTPOR - Ped hand has 220 LEDs. (Side by Side HOUSING) 16" Hand, Portland oran

MODEL SMHAND - Ped Hand has 148 LEDs (12 X 12 HOUSING) 8.75" Hand

Model LWMAN - Ped MAN has 220 LEDs. (Side by Side HOUSING) 16"

Model HMSXS - Ped Hand/Man Combo Side by side Ped hand/man, 10 watts

Obstruction Bulbs can be made to operate at 120 volt or 220-240 Volt

Obstruction BULB - Portland-Orange, bulb design, Ped Retrofit 8 watts

Obstruction BULB - Red, bulb design, Outdoors lighting. 8 watts

Obstruction BULB - Yellow, bulb design, Corridor lighting. 8 watts

Obstruction BULB - Blue, bulb design, accent lighting, 8 watts

Obstruction BULB - Blue-green, bulb design, bridge lighting, 8 watts

Obstruction BULB - Green, 8 watts

http://www.oksolar.com/n_cart/search.asp?cat=Traffic
UPS backup your traffic systems with IQFuelCell
IQ Fuel Cells for traffic backuopIQEnergy: IQ Fuel cells are now available as an alternative source for renewable energy. Unlike traditional power generators, they don't require gasoline to generate power. They also provide an alternative to solar generators because they do not depend on any external power gathering equipment. These units are compact, durable, and built to power a wide range of applications.
The Best Generator Ever!
Applications: Airports, Computer Rooms, Hospitals, Traffic, UPS


Traffic NEMA Enclosures

Power your electrical & electronics projects and applications with Solar Energy products from Oksolar.com. Our engineers can design the energy system to meet your demands. From 0.5 Watt to 100KWatts; DC or AC; and up to three-phase systems.

The SPDC/AC unit was designed to be easily expanded: power units can range from 2,000 Watts to 10,000 Watts. Its flexible platform design allows it to be easily customized for use with area lighting, remote communications, security systems, and surveillance equipment, to name a few applications. Charge power alone can be doubled or tripled with the addition of simple, cost-effective photovoltaic capture equipment.


Pre-assembled & Factory Tested

More Information >

IP Video Anywhere Solar Powered!
Protecting Critical Government Infrastructure
Military and Homeland SurveillanceSolar Powered, wireless Got facilities you need to keep an eye on? Oftentimes they're several miles from your headquarters and, worse, you can't get any electricity (let alone Ethernet) to an exterior location where you'd like to mount a camera. Companies with remote or hard to access assets, such as oil and gas pipelines, bridges or rural properties, have not had an effective, economical solution for protecting those assets.

IP Video AnyWhere Solar Powered!

IP Video solutions are the next wave in CCTV surveillance. The ability to monitor your systems from anywhere, IP video solution.

Keep an eye on your critical facilities at all times.
With OkSolar’s OkIP Video Anywhere, you can monitor sites several thousand miles away as if they were across the street. Our system facilitates remote site surveillance through energy-independent operation and allows video to be transmitted over IP without any physical lines being installed. Companies with remote or hard to access assets, such as oil and gas pipelines, bridges or rural properties, have not had an effective, economical solution for protecting those assets. Some of the features like automated archiving allow you not only to track construction progress in real time but also to retrieve past images which can be used to resolve issues quickly.


Traffic Warning SignalsClick Here for More Information on Traffic School Warning Signals
Our 12', 2 Head, Solar powered school warning flasher signal is the cost effective solution to your pedestrian safety problems. More Information > Traffic control lights, LED Traffic signals Manufacturer & Distributor, School Zone LED, School Zone LED flashing beacon, 24 7 hour led flashing beacon traffic, school zone, School warning signals, 24 hours warning Flashers, Road way warning signals, pedestrian crossing, railroad warning, ice on bridge warning, low water crossing, led beacons, speed awareness displays, Solar Powered Pedestrian Beacon, Pedestrian Beacons, 24/7 Flashing Beacon
Complete turn key Systems Solutions for Solar LightingClick Here for Low resure sodium, Area lighting, Billboards lighting, Dock lights, Park lighting, Parking lot lighting, Parkway lighting, walkway lighting, Street lighting, Transit Lighting, Outdoor area lighting.

All components needed for installation are included (except for the mounting pole). The systems are designed for installation onto a wood, concrete, or metal mounting pole. You may choose to use your own pole or we can quote the poles separately from the lighting system itself.
Click Here for PolesClick Here for Low resure sodium, Area lighting, Billboards lighting, Dock lights, Park lighting, Parking lot lighting, Parkway lighting, walkway lighting, Street lighting, Transit Lighting, Outdoor area lighting.
These units can be used for: Area lighting, Billboards lighting, Dock lights, Park lighting, Parking lot lighting, Parkway lighting, walkway lighting, Street lighting, Transit Lighting, Outdoor area lighting

Complete turn key Systems Solutions for Solar LED Lighting



Easy to retrofit LED streetlights can easily retrofit existing metal halide, high pressure sodium and mercury vapor luminaries.


Your next schedule IQLED maintenance will be in 5 to 8 years with our IQ Retrofit Lamps!



IQLED Unlike bulb streetlights, IQLED lighting modules produce very intense light in tightly control IQLED directions. There is no longer a need for reflectors or cut-off shields to minimize light pollution and trespass. With IQLED energy usage less than 20% and lifespan more than seven times that of conventional streetlights, payback occurs very early in a long life cycle.

If you are committed to savings and reduce the level of light pollution by using the most efficient IQ LED street-light fixtures and employing the latest design methods.



IQEnergy: IQ Fuel cells  Are you tired of your devices being left in the dark, when your solar energy system stops providing power? Then IQ Fuel Cells are the perfect answer for you. Are now available as an alternative source Smart fuel cell, see the future in fuel cells that power homes, Smart Fuel Cell OkSolar presents the innovative technology, Fuel Cell Energy, brennstoffzelle! Click Here>for renewable energy. Unlike traditional power generators, they don't require gasoline to generate power. They also provide an alternative to solar generators because they do not depend on any external power gathering equipment. These units are compact, durable, and built to power a wide range of applications.

The Best Generator Ever!
Applications:
Airports, Computer Rooms, HospitalsTraffic, UPS

Smart designs with IQ Fuel Cells for smart energy applications Contact us today! >

Automation - Communications- Telemetry , Highly automated communications process by which data are collected from instruments located at remote or inaccessible points and transmitted to receiving equipment for measurement, monitoring, display, and recording. Broadband VOIP/Data/802.11, Irrigation and fluid Control, LMR /SMR/Paging/Cellular/PCS. Microwave - Voice & Data, Remote communications, RTU/SCADA, Security systems, Surveillance equipment, Telemetry, Solar Area lighting, To name a few applications,
Automation - Communications - Visual Signals

Highly automated communications process by which data are collected from instruments located at remote or inaccessible points and transmitted to receiving equipment for measurement, monitoring, display, and recording can be found in our online store.
More Information >

Products for material handling applications like Underground Mining, Processing & Airport Transportation industries, Military Applications, Whether your application requires SPEED MONITORING, REMOTE CONTROLS.

Battery Backup Systems for LED Traffic Signs Increase the public safety and reduced traffic congestion by allowing traffic lights to function even during a power failure. A typical traffic signal intersection experiences eight to ten local power outages annually. With IQUPS battery backup power, some or all the traffic control signals can continue to operate. This seamless switchover to battery power increases public safety and eliminates the need to dispatch police or other service personnel to direct traffic. If all traffic signals were converted to LEDs, the battery backup system would allow full operation of the traffic signals during a power outage, thus alleviating traffic congestion.

Important feature is the battery backup system’s ability to maintain the memory of the traffic signal controller. The controller is responsible for sequencing the on and off times of the various signals. With a battery backup system, the controller’s memory can be maintained and return to normal operation once the outage has ended. This feature has eliminated the time spent to reprogram controllers after a power outage

Traffic IQUPS It is designed to provide backup power for critical LED traffic light intersections. With 1,000 watts of true sinewave power available, IQFuel Cell and maintenance free Deep cycle batteries.

Traffic IQUPS will drive most large LED systems. Its pure sinewave output is cleaner than utility power, making it ideal for all loads.

Total distortion is typically less than 1.5%. Manufactured in the USA to the highest standards possible, Traffic IQUPS system is the best choice for critical load protection. power outage knocked out traffic lights, backup generators, emergency generator

Depending on the consumers needs, the IQFuelCell automatically charges the battery with up to 100 Ah per day. As independent power supply or in combination with other systems, the IQFuelCell runs self-sufficiently for months.

The circuit is fully protected via breakers and fuses on the AC input, connection to the batteries, and DC loads. Outdoor, lockable, aluminum enclosure includes tamper-proof hardware suitable for pole or wall mounting. DC ripple <50mV.

Solar Powered Explosionproof Lights, Explosionproof light, Explosion proof light, Explosionproof Strobes, Explosion proof Strobes, Explosionproof Steady-On Lights, explosion proof light fixture is ideal for wet/damp or hazardous ... Explosion proof fixture for ceiling mountingLED Explosion Proof use LED  bulbs up to  12VDC, 24VDC, 120VAC 277VAC, 50 - 60 hertz
UL Listed for Standard 844  IQLED has been making Explosion proof Lighting systems

Construction Features Lamp compartment is factory sealed from wiring chamber, eliminating on-the-job sealing. Inspection hole provides easily accessible splice space. There is nothing to hold while splicing to line. Set screw to stem keeps fixture from turning during relamping. Three close-up plugs furnished with four hole junction box. Mounting lugs are standard.

Lamp: LED 400+ Super Bright LED's
Housings: Heavy cast aluminum. Unit withstands 1490 lbs. per square inch hydrostatic pressure during UL testing
Wiring:  Wiring is factory sealed. Inspection hole provides easy access to splice compartment
Globe: Impact and heat resistant clear prismatic design affords excellent light control
Finish: Silver Gray Epoxy powder coat
Reflectors: Heavy gauge aluminum with highly reflective white acrylic finish
Socket: Medium base glazed porcelain. Leads pass through sealing compound that separates lamp chamber from wiring compartment. Heavy gauge nickel plated copper components. Spring loaded center contact


Off-grid combined wind and diesel solutions for island nations, farms, remote areas, cell towers, exploration equipment, backup power & water pumps for natural gas mines; rapid deployment diesel & wind solutions (to include airdrop) to disaster areas for power to emergency and medical equipment, water pumps; on-grid applications for farms, factories, remote communities; and wind farm deployments. Available in 3Q 2007/08
Data Acquisition and Remote Monitoring of Energy production and distribution systems: PV Solar Powered, wind and fuel Cells generators. Data Acquisition Service
Data acquisition is the process of gathering information in an automated fashion from analog and digital measurement sources such as sensors and devices under test. Data acquisition uses a combination of PC-based measurement hardware and software to provide a flexible, user-defined measurement system.


Traffic Enclosures and Cabinets

Inverter/Charger Available in 12 - 24- and 48-volt models, it provides utility-grade output power and offers high surge capacity
105 VAC/60 Hz - 105 VAC/50 Hz - 120 VAC/60 Hz - 220 VAC/60 Hz - 230 VAC/50 Hz
-DC to DC Converters
-DC to DC Converters Din Rail
-Din Rail Linear Power Supplies
-DIN Rail power supplies
-Din Rail Single Phase Power Supplies
-Din Rail Unregulated Line Power Supplies
-Din Rail Voltage Regulator
-Inverters Accessories
-Inverters DC/AC
-Mini Power
-Power Supplies
-Power Transformers
-Transformer
Airport and Heliport landing back-up Battery Charger: 12Volts, 24 Volts, 36Volts, 48 Volts -120VAC or 230VAC Using state-of-the-art, switch-mode technology, the DLS Power Supply series is engineered with the user and variable environmental conditions in mind. Extra care has been given to insure many years of service-free operation, even when subjected to extremely harsh conditions. Batteries are charged quickly and efficiently without over charging and pumps, motors, and fans operate perfectly for prolonged life.
IOTA Engineering uses advanced switch mode technology to bring to market highly sophisticated electronic converter/power supplies at appealing affordability.

Exceptionally clean DC output insures pumps, motors, fans, and lights work perfectly. This means longer life for any connected load; virtually no AC ripple to cause static or premature failure of radio or television equipment.





OkSolar.com Serving The Industry Since 1988.
  All rights reserved. All trademarks or product names mentioned herein are the property and responsibility  of their respective owners.
Credit Pictures provided by PIX along with DOE/NREL

Email to Us | Our Philosophy  |Terms & Conditions | Powered By GeneralCommunications.com
